Transfer Switch 63-1250 a Automatic Transfer Switch CB Class 4pole ATS

Basic Info

Model NO.	PKQ2-1250A
Warranty	2 Year
Brand	Shpk
Operation	Electric
Certification	CCC, CE, ISO9001
Type	Integrated automatic transfer switch
Poles	4P
Output type	Single
Contact	Silver Contact
Function	I-0-II
Operation Type	Automatic Conversion
MOQ	1PCS
ODM&OEM	Accepted
Max. Current	63A-1600A
Protection Type	CB Type
Used Circuit Breaker	Pkm1
Rated Working Voltage	AC400V
Installation	Intergrated Type and Split Type
Transport Package	General Export Packing
Specification	set
Trademark	SHPK/OEM
Origin	Zhejiang, China
HS Code	853650
Production Capacity	3000PCS/Month

Product Description

Product Description

General:PKQ2 series automatic transfer switch is mostly used to monitor the power supply circuits. When main power failured, it will change over to backup power by automatically, thus completing the transformation of power system . At present, in particular suited for the important electricity power places where disallow to failure, in order to meet the needs of the scene. Automatic switch has self-input and selfrecover, self-input without self-recover, utility to utility, utility-generators work with variety functions, the product applied in 220V, AC 50Hz, rated current from 10A to 1250A (CB class) automatically switch products.Structure and FeaturesPKQ2 Series intelligent dual power automatic switches is made up of two units in 3 pole and 4 pole of MCCB and(auxiliary contacl, alarm contact),the mechanical interlocking transmission, intelligent controller and other components. It has the integral style and split type with two kinds mechanism. Integral controller is equipped with a base and executing agencies ; Split type is intelligent controller installed in the panel User take the base by implementing agencies to install into the cabinet controller with about 2m cables.1. Reliable mechanical interlock between the two circuit breakers and electrical interlock device. Eeliminate the two devices closing completely at the same time.2. SCM intelligent controller used to control the core hardware is simple and powerful, expansion of convenience, high reliability.3. It has a short circuit, over load protection functions, over voltage, under voltage, loss phase automatic transfer function and intelligent alarm function.4. Automatic switching external parameters can be set free.5. Operation of Intelligent motor protection6. The control circuit devices with fire, fire control center to a control signal into intelligent controller. Two sets circuit breaker will enter a stating of breaking .7. There is a computer network interface for achieving remote control four remote telemetry functions

Product Parameters
PKQ2-C-F-1250 - 1000 / 4-R

Model			PKQ2-125/250	PKQ2-400	PKQ2-630/800/1250
Mechanical life			5000	3000	2500
Electric life			1000	1000	500
Rated working system			Uninterrupted working system
Over voltage transfer adjustive value			270VAC
Set the adjustive range of under voltage			(70%~85%)Ue Adjustable Continuously
Transfer time of contact			<4s
Open-transition delay time t1			0.5~30s Adjustable Continuously
Open-transition delay time t2			0.5~30s Adjustable Continuously

Model	Match circuitbreaker	Pole	Capacity ofcircuit breakerdisjunctionIcu(kA)	Rated currentof circuit breaker(A)		RatedInsulationvoltage(V)
PKQ2-63	PKM1-63	3 Poles	50	10 , 16, 20, 3240 , 50, 63		500
		4 Poles	50
PKQ2-125	PKM1-125	3 Poles	50	16, 20, 32 , 40 ,50, 63 , 80 , 100, 125		690
		4 Poles	50
PKQ2-250	PKM1-250	3 Poles	50	125, 160, 180,200, 225, 250		690
		4 Poles	50
PKQ2-400	PKM1-400	3 Poles	65	250, 315, 350, 400		690
		4 Poles	65
PKQ2-630	PKM1-630	3 Poles	65	500, 630		690
		4 Poles	65
PKQ2-800	PKM1-800	3 Poles	75	700, 800		690
		4 Poles	75
PKQ2-1250	PKM1-1250	3 Poles	85	1000, 1250		690
		4 Poles	85

Detailed Photos

. Control device: Built-in controller

. Product structure: small volume, large current, simple structure, ATS integrative

. Characteristics: Fast switching , low failure rate, easy maintenance, reliable performance. Connection: Wiring in front of the plate

. Transformation:Powe grid to power grid, power grid to generator, and automatic recovery. Frame class: 125

. Product current:63,100,225,400,630,800, 1250A. Product classification: Circuit breaker. Number of poles: 21314 poles

. ATSE:Class CB,with overload and short circuit protection
